In Stock

Suntree SMC4Y / Parallel Solar Connector

KSh700.00

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: SUNTREE
  • Model Number: SMC4-CMMM-14 MC4 PV Y Type connector
  • Type: Solar
  • Application: solar power MC4 PV Y Type connector
  • Gender: Male & Female MC4 PV Y Type connector
  • Rated current: 30A
Category:

Description

Download Product PDF

Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: SUNTREE
  • Model Number: SMC4-CMMM-14 MC4 PV Y Type connector
  • Type: Solar
  • Application: solar power MC4 PV Y Type connector
  • Gender: Male & Female MC4 PV Y Type connector
  • Rated current: 30A
  • Withstanding Voltage: 1000vdc of MC4 PV Y Type connector
  • Contact Resistance: ≤0.3mΩ
  • Protection class: Class II
  • Temperature Range: -40 C~+90C
  • Protection Degree: IP67 MC4 PV Y Type connector
  • Unmating Force: 200 Newton MC4 PV Y Type connector
  • Contact material: Copper,silver plated of MC4 PV Y Type connector

tuv T type/Y type MC4 connector and pv cable connector mc4

  • Simple on-site processing.
  • accommodates PV cable with different insulation diameters.
  • Mating safety provided by keyed housings.
  • Multiple plugging and unplugging cycles .
  • High current carrying capacity.
  • TUV and UL approved.

MC4 Multi-Contact Connectors

Samlex’s MC4-2 Kit contains 1 male and 1 female MC4 solar panel connector. tuv T type/Y type MC4 connector and pv cable connector mc4is easy to install and uses “snap in” safety locking tabs to lock two mating connectors, thereby avoiding unintentional disconnection. Also when tuv T type/Y type MC4 connector and pv cable connector mc4 locked, the mating contacts are sealed against ingress of dust and water

Specifications are as follows

tuv T type/Y type MC4 connector and pv cable connector mc4

  • Connectors supplied with this kit are for use with wire size AWG # 10 or AWG # 12 with

outer insulation diameter of 3 – 6 mm

  • Contact diameter -4 mm
  • Maximum rated current – 30 A
  • Maximum system voltage – 1000 V
  • Degree of ingress protection when connected and properly locked – IP67
  • Temperature range 40°C to +90°C
  • TUV Rheinland – type approved, UL listed.
